Powered by 653cc gasoline engine and 24KW/48V electric motor
Gasoline engine operation powers vehicle for longer range or when you need more power
Electric motor operation powers vehicle for short distances when you want to be totally
silent you can run exclusively on the batteries
4-wheel drive operation powers vehicle with both the electric motor and the gasoline
engine simultaneously
4-wheel brakes: disc front and drum rear with regenerative braking
1200 lb. towing capacity
Total range of up to 112 miles (see estimate chart)
* white, black or camo available at additional cost
Manufacturer's Suggested Retail Price (MSRP) does not include freight, taxes, or Dealer prep charges.
MSRP is subject to change without notice, please confirm with your local authorized LANDmaster dealership.
Reference to estimated monthly payment is based on financing of 8.9% for 60 months on installment loans. Monthly payment estimate is based on MSRP and estimated taxes and fees. Financing is subject to credit approval.
Optional accessories not shown are also available. Please contact your local authorized LANDmaster dealership for more information.
Unit shown includes optional accessories
– MSRP as shown is $11107.39
** Not all LANDmaster dealers have the ability to provide installment financing. Please contact your local authorized LANDmaster dealership for more information.
| MOTOR TYPE | 48V DC / 4-stroke OHV V-twin |
TRANSMISSION | Direct drive / CVT automatic | BED MATERIAL | Structural foam – “Poly Bed” with stake pockets |
| DIFFERENTIAL | Manual lock differential | ||||
| MOTOR SIZE | 24kw at 46 ft. lbs of torque with 500 amp Curtis controller / 653cc Subaru |
TRANSAXLE | H-12 DANA gearbox / gear drive Dana-Spicer oil-filled transaxle |
BED DIMENSIONS | 35.25” L x 41.5” W x 11” D |
| BED CAPACITY | 9.25 cu.ft. / 400 lbs. | ||||
| REAR FLIP SEAT | Available when ordered as an "S" model | ||||
| SPEED | Up to 22 MPH | DRIVE | 2 Wheel drive / switch engaged on demand, 4-wheel drive |
||
| FUEL CONSUMPTION | Up to 18 MPG | TOWING CAPACITY | 1200 Lbs. | ||
| RANGE | ELECTRIC:up to 5.5 miles GAS:up to 90 miles |
VEHICLE CAPACITY | 1000 Lbs. | ||
| FRONT SUSPENSION | Double A-arm front with up to 3” travel |
PARKING BRAKE | Hand Operated | ||
| STARTING | Keyed ignition (electric motor) 12V electric keyed ignition |
HEADRESTS | Yes | ||
| REAR SUSPENSION | Articulated rear swing arm, quad adjustable shocks with 3” travel |
UNDER SEAT STORAGE | Yes | ||
| BATTERY | 4 -12V AGM sealed Deep Cycle batteries / 12V starting - 360 cca |
WARRANTY | Engine: 5 year by SUBARU All other components: 1 Year by ASW |
||
| BRAKE SYSTEM | Hydraulic Disc Front, Hydraulic Drum Rear |
||||
| ON-BOARD CHARGER | Delta Q, 48V, sealed, solid state, UL and CE compliant |
SPECIAL FEATURES | 3pt Lap/Shoulder Belts for Driver and Passenger, 35W Headlights, Polyurethane Powdered Coat Paint, 2” Rear Receiver Hitch, Dump Bed, Bench Seating, Welded Steel Frame |
||
| FRONT/REAR TIRES | 25” x 11” x 12” | ||||
| SPARK PLUG | NGK BPR4EY | DIMENSIONS | 110” L x 48” W x 75” D | ||
| FUEL CAPACITY | 5.0 gallons | WHEEL BASE | 71" | ||
| ALTERNATOR | Converter 20 amps / 30 amp | TURNING RADIUS | 8’ inside radius | ||
| LOW OIL SHUTDOWN | Oil pressure warning light | DRY WEIGHT | 1100 lbs. | ||
| SHIPPING WEIGHT | 1250 lbs. | ||||
 |
|||||
|
