Powered by 653cc gasoline engine and 24KW/48V electric motor
Gasoline engine operation powers vehicle for longer range or when you need more power
Electric motor operation powers vehicle for short distances when you want to be totally silent you can run exclusively on the batteries
4-wheel drive operation powers vehicle with both the electric motor and the gasoline engine simultaneously
4-wheel brakes: disc front and drum rear with regenerative braking
1200 lb. towing capacity
The most popular hunting accessories come standard
Locking differential to help get you through rough terrain
Total range of up to 130 miles (see estimate chart)
Manufacturer's Suggested Retail Price (MSRP) does not include freight, taxes, or Dealer prep charges.
MSRP is subject to change without notice, please confirm with your local authorized LANDmaster dealership.
Reference to estimated monthly payment is based on financing of 8.9% for 60 months on installment loans. Monthly payment estimate is based on MSRP and estimated taxes and fees. Financing is subject to credit approval.
Optional accessories not shown are also available. Please contact your local authorized LANDmaster dealership for more information.
** Not all LANDmaster dealers have the ability to provide installment financing. Please contact your local authorized LANDmaster dealership for more information.
| MOTOR TYPE | ELECTRIC:48V DC GAS:4-stroke OHV V-twin |
DIFFERENTIAL | Manual lock differential | SHIPPING WEIGHT | 1787 lbs. |
| TRANSAXLE | H-12 DANA gearbox / gear drive Dana-Spicer oil-filled transaxle |
BED MATERIAL | Steel with no flipseat | ||
| MOTOR SIZE | 24kw at 46 ft. lbs of torque with 500 amp Curtis controller / 653cc Subaru |
BED DIMENSIONS | 35.25” L x 41.5” W x 11” D | ||
| BED CAPACITY | 9.25 cu.ft. / 400 lbs. | ||||
| DRIVE | 2 Wheel drive / switch engaged on demand, 4-wheel drive |
REAR FLIP SEAT | Available as an optional accessory (p/n 2-55094) | ||
| SPEED | Up to 22 MPH | ||||
| FUEL CONSUMPTION | Up to 18 MPG | TOWING CAPACITY | 1200 Lbs. | ||
| RANGE | ELECTRIC:up to 10 miles GAS:up to 90 miles |
FRONT SUSPENSION | Double A-arm front with up to 3” travel, coil over gas reservoir shock absorbers |
VEHICLE CAPACITY | 1500 Lbs. |
| PARKING BRAKE | Hand Operated | ||||
| STARTING | Keyed ignition (electric motor) 12V electric keyed ignition |
HEADRESTS | Yes | ||
| REAR SUSPENSION | Articulated rear swing arm, quad adjustable shocks with 3” travel |
UNDER SEAT STORAGE | Yes | ||
| BATTERY | 4 – 12V Deep Cycle U.S. Batteries 12V Starting - 360 cca |
WARRANTY | Engine: 5 year by SUBARU All other components: 1 Year by ASW |
||
| BRAKE SYSTEM | Hydraulic Disc Front, Hydraulic Drum Rear |
||||
| ON-BOARD CHARGER | Delta Q, 48V, sealed, solid state, UL and CE compliant |
SPECIAL FEATURES | 3pt lap/shoulder belts for driver and passenger, 35W headlights, polyurethane powdered coat paint, 2” rear receiver hitch, dump bed, bench seating, welded steel frame, 12V auxiliary outlet for accessories | ||
| FRONT/REAR TIRES | 25” x 11” x 12” Heavy Duty 6 ply Rated |
||||
| SPARK PLUG | NGK BPR4EY | ||||
| FUEL CAPACITY | 5.0 gallons | DIMENSIONS | 142” L x 48” W x 75” D | ||
| ALTERNATOR | Converter 20 amps / 30 amp | WHEEL BASE | 104" | ||
| LOW OIL SHUTDOWN | Oil pressure warning light | TURNING RADIUS | 19.5’ inside radius | ||
| TRANSMISSION | Direct drive / CVT automatic | DRY WEIGHT | 1600 lbs. | ||
| INCLUDED ACCESSORIES | Hard top, windshield, CV guard, skid plate, 2500 Lb. capacity front winch, 2" front receiver, front hood rack | ||||
  |
|||||
|
