Landmaster LM500 from American SportWorks

Our latest 4 wheel drive model powered by a 479cc VANGUARD engine!

479cc OHV pressure lubricated 4-stroke V-twin engine

3 year engine warranty

Oil pressure warning light to protect the engine

25” tires for 14” ground clearance (8” to gearbox)

Switch engaged shift on the fly, 4 wheel drive

4 wheel hydraulic brake system

4-link, double A-arm front suspension

Articulated rear swing arm with quad adjustable shocks

Available in red, green, white*, black*or camo*

* white, black or camo available at additional cost

Manufacturer's Suggested Retail Price (MSRP) does not include freight, taxes, or Dealer prep charges.

MSRP is subject to change without notice, please confirm with your local authorized LANDmaster dealership.

Reference to estimated monthly payment is based on financing of 8.9% for 60 months with 0% down on installment loans. Monthly payment estimate is based on MSRP and estimated taxes and fees. Financing is subject to credit approval.

Optional accessories not shown are also available. Please contact your local authorized LANDmaster dealership for more information.

** Not all LANDmaster dealers have the ability to provide Sheffield financing. Please contact your local authorized LANDmaster dealership for more information.

SPECIFICATIONS

MOTOR TYPE	4-Stroke pressure lubricated OHV V-Twin	DRIVE	Switch engaged on demand, 4 wheel drive	BED DIMENSIONS	35.25” L x 41.5” W x 11” D
	4-Stroke pressure lubricated OHV V-Twin		Switch engaged on demand, 4 wheel drive	BED CAPACITY	9.25 cu.ft. / 500 lbs.
MOTOR SIZE	479cc VANGUARD by Briggs & Stratton	FRONT SUSPENSION	4-Link double A-arm with up to 5” travel	REAR FLIP SEAT	Available when ordered as an "S" model
	479cc VANGUARD by Briggs & Stratton		4-Link double A-arm with up to 5” travel		Available when ordered as an "S" model
SPEED	Up to 24 mph	REAR SUSPENSION	Articulated rear swing arm, quad adj.with 3” Travel	TOWING CAPACITY	1200 Lbs.
FUEL CONSUMPTION	Up to 18 mpg		Articulated rear swing arm, quad adj.with 3” Travel	VEHICLE CAPACITY	1000 Lbs.
RANGE	Up to 90 miles	BRAKE SYSTEM	Hydraulic disc front, hydraulic drum rear	PARKING BRAKE	Hand operated
STARTING	12V Electric ignition		Hydraulic disc front, hydraulic drum rear	HEADRESTS	Yes
BATTERY	360 cca	FRONT TIRES	25" x 11" x 12"	UNDER SEAT STORAGE	yes
BACKUP-RECOIL START	No	REAR TIRES	25" x 11" x12"	WARRANTY	Engine: 3 year by B & S All other components: 1 year by ASW
GROUND CLEARANCE	14” (8” to gearbox)	DIMENSIONS	110” L x 48” W x 75” D
FUEL CAPACITY	5.0 Gallons	WHEEL BASE	71"
ALTERNATOR	16 Amp	TURNING RADIUS	9.5' - Inside radius	SPECIAL FEATURES	3pt lap/shoulder belts for driver and passenger, 35W headlights, polyurethane powder paint, 2” rear receiver hitch, dump bed, bench seating, welded steel frame, 12V auxiliary outlet for accessories
LOW OIL SHUTDOWN	Oil pressure warning light	DRY WEIGHT	1000 Lbs.
TRANSMISSION	CVT automatic	SHIPPING WEIGHT	1100 Lbs.
DIFFERENTIAL	Locking differential	BED MATERIAL	Structural foam – “Poly Bed” with stake pockets
TRANSAXLE	Gear drive Dana-Spicer oil-filled transaxle		Structural foam – “Poly Bed” with stake pockets
	Gear drive Dana-Spicer oil-filled transaxle
